Aten DisplayPort Slim KVM over IP Transmitter, supports up to 1920 x 1200 @ 60 Hz

Product Description

Aten DisplayPort Slim KVM over IP Transmitter, supports up to 1920 x 1200 @ 60 Hz Advance processor provides lossless and low latency video transmissions up to 1920 x 1200 @ 60Hz; 24-bit color depth; compliant with DP 1.2 and HDCP 1.3 Flexible connections - allows multiple extender and matrix connections for Multi-Display installations and Video Wall applications Slim, light, and fanless design Hardware Advance processor provides lossless and low latency video transmissions up to 1920 x 1200 @ 60Hz; 24-bit color depth Support standard HDMI resolutions from 640 x 480 up to 1920 x 1200 USB Virtual Media Support Compliant with DP 1.2 and HDCP 1.3 Auto-MDIX – automatically detects cable type Built-in 8KV/15KV ESD protection and 1KV surge protection Slim, light and fanless design for silent operations that are energy efficient Support connection via Gigabit Ethernet port Rack Mountable* and Wall Mountable Connectors KVM Ports 1 x USB Type B Female (White) 1 x DisplayPort Female (Black) 1 x DB-9 Female (Black) Power 1 x DC Jack (Black) 1 x 3-Pole Terminal Block Connector (Green) LAN Ports 1 x RJ-45 (Black) Switches Reset 1 x Semi-recessed Pushbutton LEDs 10/100/1000 Mbps 1 (10: Orange / 100: Orange & Green / 1000: Green) Power 1 (Blue) Emulation Keyboard / Mouse USB Power Consumption DC5V:4.75W:22BTU DC48V:6.97W:33BTU Video Resolution Up to 1920 x 1200 @ 60Hz Environmental Operating Temperature 0–50°C Storage Temperature -20–60°C Humidity 0–95% RH, Non-condensing Physical Properties Housing Metal Weight 0.65 kg ( 1.43 lb ) Dimensions (L x W x H) 18.20 x 11.75 x 2.87 cm (7.17 x 4.63 x 1.13 in.) Note For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
